TD-X2-B
- - Work with proximity card
- - Available for 60/85,55/72 mortise or single latch
- - Work with 4pcs AAA alkaline battery
- - Emergency key for backup use
- - Work with Wi-Fi&BLE dual module
- - Support dynamic passcode
- - With electronic anti lock function
Tuya Smart Digital Fingerprint Lock
Work with proximity cardAluminum alloy panel/handle
Black oxidation treatment
Available for 60/85,55/72 mortise or single latch
Work with 4pcs AAA alkaline battery
Emergency key for backup use
300,000 times life test
Work with Wi-Fi&BLE dual module
Support dynamic passcode
With electronic anti lock function
APP:Tuya APP
Lock Dimension: 60x250x21mm
Package Informations:
Inner box: 330x174x120mm/2.0kgs
10pcs/carton/21kgs
Exterior carton: 615x377x365mm
Parameters
Static current
≦50uA
Dynamiccurrent
≦180mA
Administratorsnumber
9
Fingerprint number
100
Fingerprint+password+card capacity
200
Fingerprint Sensor
Semiconductor
Fingerprint contrast time
≦0.6Second
Fingerprint identification Angle
360°
False Rejection Rate
≦0.1%
False Recognition Rate
≦0.0001%
Reaction time
≦0.1Second
Power type
6V
Emergency power
5VDC
Working temperature
-25℃-60℃
Working Relative Humidity
20%~90%RH
Human voice
Yes
Keyboard
Touch standard 12-bit keyboard
PasswordLength
4-8digits
Phantom password
32 digits
Lowvoltage alarm
4.6+0.2V
Unlock time
≦1Second
