TD-L604-01
TD-L604-01

TD-L604-01

  • - Electric bolt lock.
  • - Two-core standard model, DC12V input.
Share to
Specifications

Lock Size 200 x 32 x 40mm
Strike Plate Size 90 x 26 x 2mm
Lock Bolt Size 16 x 15.5 x 15.5mm
Weight 860g
Material Aluminum
Feature fail safe (unlock when power off)
Input Voltage DC 12V
Start Current 900mA
Standby Current 330mA
Working Temperature -10~55
Working Humidity 0~90%
Lock Delay Time 0/2.5/5/9 second adjustable
Solid Bolt polishing surface, 800kg holding force
Suitable For wooden door, glass door, metal door
Induction Distance 8mm
