TD-10MAT
- - Ultra-thin body, Appearance of engineering ABS plastic material;
- - Multiple working modes: TCP/IP networking, offline;
- - Integrates a variety of unlocking methods: card swiping, management center, and exit button;
Ultra-thin body, with built-in 86 box installation method, the visible thickness after installation is only 8MM;
Appearance of engineering ABS plastic material;
Multiple working modes: TCP/IP networking, offline
Integrates a variety of unlocking methods: card swiping, management center, and exit button;
Support multiple advanced access control functions;
Can store user data, support stand-alone operation in disconnected mode;
Can carry out local management, support login background settings, manage device parameters;
Parameters
| Working voltage | DC12V |
| Standby current | 110mA±20mA |
| Working current | 150mA±50mA |
| OS | Embedded |
| CPU | ARM Cortex M3 |
| Memory | 20K flash: 128K+8M |
| Reading distance | 0~4cm |
| Card capacity | 1000 |
| Record capacity | 1000 |
| Working temperature | -40℃~70℃ |
| Working humidity | 10%~93% |
| Appearance material | engineering ABS plastic |
| Installation method | embedded with 86 boxes, the inner depth of 86 boxes is required to be ≥ 50MM |
| Appearance size | 86x86x28MM |
| Bare size | 86*86*8MM |
| External Interface | |
| Power supply | 12V power interface |
| Network | 1 RJ45 10M/100M adaptive Ethernet port |
| 485 | 1 group of 485 bus communication interface |
| Exit key | 1 set of exit key signal detection input interface |
| Door sensor | 1 set of door sensor signal detection input interface |
| Unlocking | 1 group of common ports, normally open and normally closed ports |
