TD-L280-BMY-01
- - Double door magnetic lock.
- - Pulling force ≧280kg*2, power off to unlock, with lock status signal output, DC12V.
Specifications
| Material | aluminum alloy |
| Weight | 2.2kg |
| Lock Size | 500Lx48.8Wx27.9H(mm) |
| Armature Plate Dimension | 180Lx38.8Wx13H(mm) |
| Pulling Force | 280kg * 2 |
| Input Voltage | DC 12/24V |
| Current | 12V/520mA *2 or 24V/260mA *2 |
| Signal Output | lock signal(NO/NC/COM) |
| Feature | MOV Provides Reverse Current Protection |
| LED Indicator | Red shows locked; Green shows unlocked |
| Suitable | Wooden door, Glass door, Metal door, Fireproof door |
