TD-X2-B
- - Multiple Unlocking Options: Can be unlocked using a fingerprint, key, or the Tuya Smart App for added convenience.
- - Durable Build: Made from aluminum alloy, offering strength and longevity in a sleek finish.
- - High Fingerprint Capacity: Can store up to 50 fingerprints, accommodating multiple users.
- - Advanced Fingerprint Sensor: Features a semiconductor sensor with 360° recognition for accurate identification.
- - Efficient Power Management: Operates on 4pcs AAA batteries with an emergency power port for backup power supply.
- - Smart Connectivity: Equipped with Bluetooth functionality for integration with the Tuya Smart App, enabling remote control and monitoring.
Specifications
| Unlock Method | Fingerprint, key, Tuya Smart App |
| Lock Dimension |
Front: L75×Ø76mm Back: L73×Ø76mm |
| Weight | 0.4kg |
| Color | Black |
| Material | Aluminum alloy |
| Lock Mortise Size | 97×57×25mm |
| Fingerprint Capacity | Total 50 sets |
| Fingerprint Sensor | Semiconductor |
| Fingerprint Contrast time | ≦1s |
| Fingerprint Identification Angle | 360° |
| False Rejection Rate | ≦1% |
| False Acceptance Rate | ≦0.001% |
| Battery | 4pcs AAA batteries |
| Operating Voltage | DC6V |
| Emergency Power | USB port, DC5V |
| Static Current | ≦50uA |
| Dynamic Current | ≦200mA |
| Working Temperature | -25℃~85℃ |
| Working Relative Humidity | 20%~90% |
| Unlock Time | ≦1s |
| Double-Locking | Support |
| Anti-Static | Support |
| Tuya Smart App | Bluetooth connection |
