  • - Unlock Methods: Offers multiple secure unlocking methods including facial recognition, fingerprint, password, IC card, Tuya App, and traditional key.
  • - Material: Constructed with durable materials, this lock features an aluminum alloy build with a baking paint surface and IMD coating, ensuring longevity and resistance to wear.
  • - HD Camera: Equipped with a high-definition camera, provides added security and facial recognition features.
  • - Screen Display: Features a 4.0" IPS screen for user-friendly interaction and visual feedback.
  • - Capacity: Can store up to 300 sets of face, card, fingerprint, and password data, providing ample space for user profiles.
  • - Security Features: Supports 20-digit anti peeping password, enhancing security measures.
  • - Fingerprint Sensor: Utilizing a semiconductor fingerprint sensor, ensures quick and accurate fingerprint recognition with a contrast time of less than 1s.
  • - App Integration: Seamlessly integrated with Tuya App for remote control and unlocking.
Share to


Unlock Method Facial recognition, fingerprint, password, IC card, key, Tuya App
Lock Dimension 425x69x65mm
Color Grey
Material Aluminum alloy, baking paint surface, IMD coating
HD Camera 2 million pixels
Screen Display Front: 0.96″ OLED screen
Back: 4.0″ IPS screen
Lock Mortise Size 6068
Face & Card & Fingerprint & PIN Capacity Total 300 sets
Password Length 4~10 digits
Phantom Password 20 digits
Fingerprint Sensor Semiconductor
Fingerprint Contrast time 1s
Fingerprint Identification Angle 360°
False Rejection Rate 1%
False Recognition Rate 0.001%
Reaction Time 1s
Battery 4200mAh lithium battery
Operating Voltage 7.0V~8.4V
Emergency Power USB port, 5V
Static Current 80uA
Dynamic Current 300mA
Working Temperature -20~40
Working Relative Humidity 10%~60%
Voice Assistant Support
Keypad Standard 12-bit touch keypad
Low Voltage Alarm 7.2V
Unlock Time 1s
System Restart USB port
Double-Locking Support
Connect to Tuya App 2.4G WiFi
Advanced Functions Snapshot, intercom, alarm, one-key on/off
